3603396
Source power type
6 LED
Colour temperature
2700K
CRI:
>90
Source power:
2,0 W
Nominal flux:
175 lm
Real flux:
110 lm
Optics:
Diffusa lm
Power Supply Unit:
24V
Operating frequency:
DC
Dimmable:
PWM
Safety class:
III
Protection Rating:
IP65
Breaking Strength:
IK05
DarkSky:
1
Head and stem in stainless steel AISI 316L. Remote driver with constant voltage driver 24V DC to be wired in parallel. Ground stake in Technopolymer with fiberglass. Diffuser with special surface treatment so to optimize light distribution and limit glare.
8956074
IP67 Power supply (24V DC - 150W)
8956104
IP20 Power supply (24V DC - 30W)
8956172
IP67 Power supply (24V DC - 40W)
8956021
Power supply DALI (24V DC - 60W) IP67
8956313
Power supply DALI (24V DC - 120W) IP67
8956221
Power supply (24V DC - 100W) IP67
8956360
Connection box ON-OFF
8956361
Connection box DALI
8956362
Connection box CASAMBI
8956227
IP20 Power supply (24V DC - 100W)
8956228
IP20 Power supply (24V DC - 150W)
8956222
Power supply DALI (24V DC - 24W) IP20
8956223
Power supply DALI (24V DC - 75W) IP20
8956224
Power supply DALI (24V DC - 150W) IP20
8956226
Power supply DALI (24V DC - 24W) IP67
